2nd Generation Dynamic Audi Led Emblem for S Models S3 S4 S5 S6 S7 S8

Original price was: $219.00.Current price is: $149.00.

How does the Dynamic Audi Led Emblem work

  1. This 2nd dynamic Audi emblem has four Dynamic Effects, no need for any apps to control it. Just connect to your Daytime running lights /headlights/ taillight thread.
  2. Every time when you unlock your car, it shows the dynamic effects. You can not select the animation, it works automatically; When you drive, it always lights; When you lock it shows the lock animation. (Please Check the video in the description)
  3. If you want only illuminates at night, you can wire headlights. If you want illuminates when driving, you can wire acc box and battery +.
  4. There are two Colors you can choose from Black and Silver
  5. 2nd generation Dynamic Audi light has better quality, no need to worry about waterproof problems.
  6. 3-Year Warranty, any quality problem contact us.
SKU: 597 Category: Tags: ,

Description

What’s the Dynamic of the 2nd Generation Dynamic Audi Led Emblem for S Models S3 S4 S5 S6 S7 S8 ( Four Dynamic Effects), you can check via this video.

How to choose the Dynamic Audi Led Emblem that fits my Audi S Models S3 S4 S5 S6 S7 S8?

  • You can choose the Model Year According to the Option.



What’s the color of the Dynamic Audi Emblem

  • We have two colors: Black and Silver.



What are the features of the Second Generation Dynamic Audi Led Emblem S Models S3 S4 S5 S6 S7 S8( Four Dynamic Effects)

  • 4 Animations – Outside in, up and down, chain linking motion, and flashing on and off – lighting up when you first start your car or lock your Audi.
  • Slots directly to the front badge location on Audi vehicles.
  • Coming in two color options including chrome-silver and gloss black.
  • Unique Audi emblem, matching OEM dimensions.
  • Easy to install with 8 clips.
  • Glossy finish in Black or Chrome.
  • Brand-New Second-Generation Design!

Order Includes:

  • 1* LED Dynamic Audi Emblem
  • Power supply: DC12V+/-10%
  • The wire length:0.6
  • Power:2W
  • Voltage:13(V)
  • Current:0.1(A)

How to Install 2nd Generation Dynamic Audi Led Emblem ( Four Dynamic Effects)

How to connect the wiring of the dynamic Audi Led Emblem Light?

When you connect the wires please pay attention to the order. Connect the yellow wire and black wire first, then connect the red wire. Don’t connect the red wire then connect the yellow wire, this is incorrect.

First of all, make sure the yellow wire is powered.

If you do not wish to connect separately, you can connect the red wires and yellow wires together. This will remove the lock animation feature.

1.[Yellow Wire] connect Battery +

2.[Black Wire] connect Grounding –

3.[Red Wire] connect low beam light ACC

What is the voltage/ampere/Watts of the dynamic Emblem Light?

  • 12V/0.48A/5.76W



Additional information

Car Type

S3 (2013–2020), S3(2006-2012), S3(2021-2024), S4(2013-2019), S4(2020-2024), S5 B8/8T(2007–2017), S5 B9(2020–2024), S6(2006–2011), S6(2012–2018), S6(2019–UP), S7(2010–2018), S7(2019–2024, S8(2007-2009), S8(2012-2018), S8(2019-2020)

Color

Black, Silver

LED Color

White

Brand

Floating Center Caps
